- Compact design
- Quick and easy clamping of components
Description
Material
Carbon steel.
Version
Black oxidized.
Note
Dimension A refers to the distance from the workpiece to screw center (cam screw).
Style B with clamp plate is recommended to minimize scratches on the workpiece.
Style B with clamp plate is recommended to minimize scratches on the workpiece.
Advantages
- Compact design
- Quick and easy clamping of components
- Quick and easy clamping of components
Drawing reference
(1) clamping plate
Accessory
Clamping plate 04431-15.
