- Serve as supports for workpieces and fixtures
- Toleranced dimension for exact positioning
- Suitable as feet for fixtures
- Hardened and ground
- Support faces without centerbore
Description
Material
Tool steel.
Version
Hardened and ground.
Note
Thrust Bolts style A serve as a mount for workpieces and fixtures.
Straight Bolts style B serve to position workpieces and fixture parts in holes with locating dimensions.
The flattened style C can be used to bridge tolerances in hole spacing or to secure the part to be positioned in one direction only.
Style A and B can also be used as hardened stop and as foot for fixtures.
For similar bolts see 03120, 03130, 03140 and 03150.
Straight Bolts style B serve to position workpieces and fixture parts in holes with locating dimensions.
The flattened style C can be used to bridge tolerances in hole spacing or to secure the part to be positioned in one direction only.
Style A and B can also be used as hardened stop and as foot for fixtures.
For similar bolts see 03120, 03130, 03140 and 03150.
